Mandrel built EPDM rubber hose designed for the transfer of water in motor vehicle cooling systems
Picture for illustration purposes only.
| Product Code | Size | Diameter ID | Diameter OD | Working Pressure | Burst Pressure | Weight | Roll Length |
|---|---|---|---|---|---|---|---|
| SRH013 | 13mm | 13 | 19 | 45 | 135 | 0.2 | 913mm |
| SRH016 | 16mm | 16 | 23 | 45 | 135 | 0.24 | 913mm |
| SRH019 | 19mm | 19 | 27 | 45 | 135 | 0.31 | 913mm |
| SRH022 | 22mm | 22 | 30 | 45 | 135 | 0.32 | 913mm |
| SRH025 | 25mm | 25 | 33 | 45 | 135 | 0.35 | 913mm |
| SRH029 | 29mm | 29 | 39 | 45 | 135 | 0.4 | 913mm |
| SRH032 | 32mm | 32 | 41 | 45 | 135 | 0.55 | 913mm |
| SRH035 | 35mm | 35 | 44 | 45 | 135 | 0.6 | 913mm |
| SRH038 | 38mm | 38 | 47 | 45 | 135 | 0.73 | 913mm |
| SRH041 | 41mm | 41 | 51 | 45 | 135 | 0.77 | 913mm |
| SRH044 | 45mm | 45 | 54 | 45 | 135 | 0.8 | 913mm |
| SRH048 | 48mm | 48 | 57 | 45 | 135 | 0.97 | 913mm |
| SRH051 | 51mm | 51 | 61 | 45 | 135 | 1.02 | 913mm |
| SRH054 | 54mm | 54 | 64 | 45 | 135 | 1.1 | 913mm |
| SRH057 | 57mm | 57 | 67 | 45 | 135 | 1.2 | 913mm |
| SRH060 | 60mm | 60 | 70 | 45 | 135 | 1.23 | 913mm |
| SRH064 | 63mm | 63 | 73 | 45 | 135 | 1.25 | 913mm |
| SRH067 | 67mm | 67 | 77 | 45 | 135 | 1.38 | 913mm |
| SRH070 | 70mm | 70 | 80 | 45 | 135 | 1.4 | 913mm |
| SRH073 | 73mm | 73 | 83 | 45 | 135 | 1.45 | 913mm |
| SRH075 | 76mm | 76 | 86 | 45 | 135 | 1.51 | 913mm |
| SRH080 | 80mm | 80 | 90 | 45 | 135 | 1.98 | 913mm |
| SRH089 | 89mm | 89 | 99 | 45 | 135 | 2.04 | 913mm |
| SRH102 | 102mm | 102 | 112 | 45 | 135 | 2.15 | 913mm |
| SRH114 | 114mm | 114 | 127 | 45 | 135 | 2.4 | 913mm |
| SRH127 | 127mm | 127 | 140 | 45 | 135 | 2.48 | 913mm |
| SRH140 | 140mm | 140 | 152 | 45 | 135 | 2.92 | 913mm |
| SRH152 | 152mm | 152 | 167 | 45 | 135 | 3.36 | 913mm |
