Mandrel built rubber hose designed for the transfer of water in both positive and negative pressure applications. With an abrasive resistant tube it can also be used the suction and delivery of light slurries and other light to medium abrasive materials.
On request QuoteYou'll get pricing for this item in the quote you submit — for now, just add it to your cart.
Picture for illustration purposes only.
| Product Code | Size | Diameter ID | Diameter OD | Working Pressure | Burst Pressure | Weight | Roll Length |
|---|---|---|---|---|---|---|---|
| D214-019 | 3/4″ | 19 | 29 | 150 | 450 | 0.76 | 20 | 60 |
| D214-025 | 1″ | 25 | 36 | 150 | 450 | 0.95 | 20 | 60 |
| D214-032 | 1 1/4″ | 32 | 43 | 150 | 450 | 1.05 | 20 | 60 |
| D214-038 | 1 1/2″ | 38 | 49 | 150 | 450 | 1.3 | 20 | 60 |
| D214-044 | 1 3/4″ | 44 | 56 | 150 | 450 | 1.5 | 20 | 60 |
| D214-050 | 2″ | 51 | 63 | 150 | 450 | 1.92 | 20 | 60 |
| D214-063 | 2 1/2″ | 63 | 77 | 150 | 450 | 2.55 | 20 | 60 |
| D214-075 | 3″ | 76 | 89 | 150 | 450 | 3.1 | 20 | 60 |
| D214-100 | 4″ | 102 | 118 | 150 | 450 | 4.39 | 20 | 60 |
| D214-125 | 5″ | 127 | 146 | 150 | 450 | 6.98 | 20 | 30 |
| D214-150 | 6″ | 152 | 170 | 150 | 450 | 8.99 | 20 | 30 |
| D214-200 | 8″ | 204 | 223 | 150 | 450 | 13.61 | 12 |
| D214-250 | 10″ | 254 | 282 | 150 | 450 | 19.74 | 12 |
| D214-300 | 12″ | 305 | 335 | 150 | 450 | 24.41 | 12 |
